PCB Manufacturing
Customized PCB Fabrication
Your Trusted Partner for PCB bare board fabrication
Having been contributed ourselves to PCB industry more than 10 years,Unit Circuits has rich experience in fabricating FR4 PCBs, Flex/Flex-Rigid PCBs, Aluminum PCBs, Metal Core PCBs (MCPCBs), HDI PCBs, High-Frequency PCBs, High-Tg PCBs, Thick Copper PCBs and many other advanced PCB products.
PCB Manufacturing Capability
| Material | FR4,Arlon,Metal Core,Taconic,Nelco,Isola,Halogen Free,Rogers,PTFE,PI,ect |
| Max. Finishing Board Size | 1500X610 mm |
| Min. Board Thickness | 0.1mm for L ≤2, 0.3mm for 4L&above |
| Max. Board Thickness | 10.0 mm |
| Buried / Blind Via (Non-cross) | 0.1mm |
| Aspect ration | 20:1 |
| Min. Drilling Size(Mechanical) | 0.15 mm |
| Tolerance PTH/ Pressing fit hole /NPTH | +/-0.0762 mm / +/-0.05mm / +/-0.05mm |
| Max. Layer Count | 50 |
| Max. copper (inner/outer) | 6OZ/12 OZ |
| Drill tolerance | +/-2mil |
| Layer to layer registration | +/-3mil |
| Min. line width/space | 2.5/2.5mil |
| BGA pitch | 8mil |
| Surface treatment | HASL, Lead free HASL, ENIG, Immersion silver/Tin, OSP |
Blind/Buried Vias or Microvias
Via in Pad
Countersink/Counterbore Hole
Half-cut/Castellated Hole
Gold Fingers
Edge Plating
Kapton Tape
RoHS Compatibility
FAQs about PCB Manufacturing
You can count on us to manufacture a wide range of PCBs, including single-sided, double-sided, multilayer, rigid, flex, and rigid-flex boards, all customized to fit your project needs.
Quality is our top priority. We implement stringent quality control measures, including AOI, X-ray inspection, and electrical testing, to ensure your PCBs meet the highest standards and your exact specifications.
We offer a variety of materials such as FR4, Rogers, aluminum, and flexible substrates. You can choose the best material based on your project’s performance requirements and budget.
Absolutely! Whether you need a small prototype run or large-scale production, our facilities are equipped to handle orders of any size, ensuring you receive your PCBs on time and within budget.
Our standard lead times vary depending on the complexity and volume of your order. However, we pride ourselves on our fast turnaround times, often delivering within a few weeks.
Yes, we do! Our experienced engineers can provide design support and consultation to help you optimize your PCB layouts for performance, manufacturability, and cost-efficiency.
Definitely! We specialize in rapid prototyping, allowing you to quickly test and iterate your designs before committing to full-scale production.
We perform comprehensive testing, including electrical testing, thermal stress testing, and impedance testing, to ensure your PCBs function perfectly in your final application.
